PRODUCT PARAMETERS
Product Description
| Brand | Vehicle Master | Vehicle Master |
| Application | Heavy Duty Loading | Heavy Duty Loading |
| Axle | 3 Axles | 4 Axles |
| Loading Capacity | 30 – 120 Tons | 30 – 150 Tons |
| L*W*H | 13000*3000*1760mm | 13000*3000*1760mm |
| Ladder | Mechanical Spring/Hydraulic | Mechanical Spring/Hydraulic |
| Goose Neck Detachable | Available | Available |
| Multi-Axles | Available | Available |
| Steering Axles | Available | Available |
| Tire Style | Covered or Uncovered | Covered or Uncovered |
| Main Beam | Material: Q345/T700 | |
| Height: 500mm | ||
| Upper Plate: 24mm | ||
| Middle Plate: 14mm | ||
| Lower Plate: 26mm | ||
| Platform Thickness | 4mm | |
| Axle | 3/4 Axles *13/16 Ton–Vehicle Master/FUWA/BPW/Other | |
| Tire | 12R22.5/8.25r20 (12/16 Pieces)–Linglong/Triangle/Double-Coin/Bridgestone/Other | |
| Rim | 9.00*22.5/6.5-20 (12/16 Pieces)–Steel/Aluminum | |
| Leaf Spring | 90mm*13mm*10/90mm*16mm*10Pcs | |
| Suspension System: | Mechanical/Air Suspension | |
| Ladder | Mechanical Spring/Hydraulic | |
| King Pin | #50(2″)/#90(3.5″)–JOST/Other Brand,Changeable | |
| Landing Gear | 28 Tons Two Speed–JOST/Other Brand | |
| Tool Box | Steel/Aluminum | |
| Widened Parts | Available | |
| Painting | Polyurethane combination painting | |
FAQs
How long will I receive the truck after payment? And what is your payment term?
Usually we accept T/T payment term for truck orders, but L/C payment is also acceptable under some special circumstances. About delivery time, normally it takes 30 days to produce your truck and deliver it to the port for loading after receiving your payment, but if you need it urgently, we can deliver it with the stored truck within one week.
Why is your price a little higher than other Chinese brand trucks?
Our machinery adopt durable top brand engine, high configuration, with top quality, thus the cost will be a little higher.
What warranty do you provide for your Dongfeng truck?
We provide 12 months warranty calculating from the machinery equipment arrive at destination port. During the warranty time, we will provide free spare parts if you need to change the damaged parts at first time when you contact with us. And provide you the cost price of spare parts after the warranty time.
